• CJ1W-OD232 Transistor Output Unit (32 Points)

• Name : 32-point Transistor Output Unit with MIL Connector (Sourcing Outputs)

• Model : CJ1W-OD232

• Rated Voltage : 24 VDC

• Operating Load Voltage Range : 20.4 to 26.4 VDC

• Maximum Load Current : 0.5 A/point, 2.0 A/common, 4.0 A/Unit

• Leakage Current : 0.1 mA max.

• Residual Voltage : 1.5 V max.

• ON Response Time : 0.5 ms max.

• OFF Response Time : 1.0 ms max.

• Load Short-circuit Protection : Detection current: 0.7 to 2.5 A, Automatic restart after error clearance.

• Insulation Resistance : 20 MO between the external terminals and the GR terminal (100 VDC)

• Dielectric Strength : 1,000 VAC between the external terminals and the GR terminal for 1 minute at a leakage current of 10 mA max.

• Number of Circuits : 32 (16 points/common, 2 circuits)

• Internal Current Consumption : 5 VDC 150 mA max.

• External Power Supply : 20.4 to 26.4 VDC, 70 mA min.

• Weight : 80 g max.

• Accessories : None

• Shipping Weight: 1 Kg
